Battery and Control Board Guide
Do you need a little help selecting a backup battery unit or a control board for a FAAC gate operator? Our selection guide is the only one of its kind and comes directly from manufacturer specifications. Whether you're searching for the control board for a Model 770 or a backup battery for a 415 swing gate operator, this guide will help you find the right replacement for the job.
| FAAC Gate Operator | Gate Opener Type | Control Board | Battery Back-up Unit |
| Model 390 | Low Voltage Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model 400 | Hydraulic Swing Gate Operator | 790919 115V 455 D Control Panel 790926 220V 455 D Control Panel |
3520 Single 115V 3522 Dual 115V 3521 Single 220V 3523 Dual 220V |
| Model 402 | Swing Gate Operator | 790919 115V 455 D Control Panel 790926 220V 455 D Control Panel |
3520 Single 115V 3522 Dual 115V 3521 Single 220V 3523 Dual 220V |
| Model 415 | Low Voltage Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model 412 | Swing Gate Operator | 790919 115V 455 D Control Panel 790926 220V 455 D Control Panel |
3520 Single 115V 3522 Dual 115V 3521 Single 220V 3523 Dual 220V |
| Model 415 | Swing Gate Operator | 790919 115V 455 D Control Panel 790926 220V 455 D Control Panel |
3520 Single 115V or 3522 Dual 115V |
| Model S418H | Hydraulic Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model S450H | Hydraulic Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model 615 | Barrier Gate Operator | 790919 115V 455 D Control Panel 790926 220V 455 D Control Panel |
N / A |
| Model 620 | Barrier Gate Operator | 20227125 115V 624 BLD Control Panel 63000395 220V 624 BLD Control Panel |
N / A |
| Model 640 | Barrier Gate Operator | 20227125 115V 624 BLD Control Panel 63000395 220V 624 BLD Control Panel |
N / A |
| Model 750 | In-Ground Swing Gate Operator | 790919 455 D 115 V Control Board 790926 455 D 220 V Control Board |
3520 Single 115V 3522 Dual 115V 3521 Single 220V 3523 Dual 220V |
| Model 760 | In-Ground Swing Gate Operator | 790919 455 D 115 V Control Board 790926 455 D 220 V Control Board |
3520 Single 115V 3522 Dual 115V 3521 Single 220V 3523 Dual 220V |
| Model 770 | Low Voltage Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model S800H | Hydraulic Swing Gate Operator | 202025 E024U Control Board 750007 Power Supply |
3540 Battery |
| Model DSL 2000 | Heavy-Duty Slide Gate Operator | N / A | Built-In Battery Backup |
| Model DSW 2000 | Heavy-Duty Swing Gate Operator | N / A | Built-In Battery Backup |
