Surge Protector for Up To 4 Low Voltage Circuits (5V, 12V, or 24V) - FAAC 2357

Details

Surge Protector for Up To 4 Low Voltage Circuits (5V, 12V, or 24V) - FAAC 2357

The FAAC 2357 Surge Protector for low voltage circuits is a compact, screw-terminal surge protection device that safeguards up to four circuits, including power, LED, data, and audible lines, across 5 V, 12 V, or 24 V systems. Engineered with self-restoring functionality, it automatically returns to service following typical transient events, ensuring continuous protection with minimal maintenance. The unit offers line-to-ground surge protection and connects easily using #22–#16 AWG screw terminals. Its condensed design allows it to fit into most low-voltage control enclosures or access panels with ease.

Features:

• Surge protection device for up to 4 Low Voltage circuits
• Protects power, LED and data lines
• Protection modes: Line-Ground (all)
• Connection method: #22-#16 AWG screw terminals
• Self restoring
• Dimensions: 1.6 x 3.0 x 1.6 in (41x76x41mm)
