FAAC 400 CBAC EG Long Hydraulic Swing Gate Opener Arm with Arctic Oil 115V (18ft / 1500 lbs.) - FAAC 1042021277

Operates swing gates up to 18 feet long and 1500 lbs. Includes operator only. Use to turn your single kit into a dual Primary/Secondary (bi-parting) kit, or use it as a replacement operator.
Part Number: 1042021277
$1,460.70 each
$1,460.70 each
OR


Details

FAAC 400 CBAC EG Long Hydraulic Swing Gate Opener Arm with Arctic Oil 115V (18ft / 1500 lbs.) - FAAC 1042021277

Perfect for apartment, subdivision, commercial, condo, industrial and residential use, the 400 CBAC EG long gate operator from FAAC features quiet operation, key protected manual release, and self lubrication.

Operates swing gates up to 18 feet long and 1500 lbs. Includes operator only. Use to turn your single kit into a dual Primary/Secondary (bi-parting) kit, or use it as a replacement operator.

Features:

  • Wide and versatile range from residential to heavy industrial gates
  • Hydraulic lock of the gate in open and/or closed positions
  • Quiet operation
  • Self lubricating for long life
  • Key protected manual release
  • Arctic oil

Technical Specs:

  • Input Voltage: 115 VAC (+10% -6%)
  • Power: 220 W
  • Current: 2 A
  • Motor Rotation Speed: 1400 r.p.m.
  • Thrust Capacitor: 25 uF
  • Operating Ambient Temperature: -33 Degrees F to 165 Degrees F (-36 Degrees C to +75 Degrees C)
  • Thermal Protection on Motor: 248 Degrees F (120 Degrees C)
  • Protection Class: IP 55
  • Dimensions: 50.6 x 4.4 x 3.3 in (1,285x113x85 mm)
  • Hydraulic Locking: Opening and closing
  • Maximum Leaf Length: 18 ft (5.5 m)
  • Maximum Leaf Weight: 1500 lb (680 Kg)
  • Thrust Force: 1045 lbf (465 daN)
  • Pump Flow Rate (l/min): 1.5
  • Rod Extension Speed: 0.6 in/sec (1.5 cm/sec)
  • Effective Rod Stroke: 15 in (380mm)
  • Use Frequency (cycles per hour): 50

Manual

Brochure

SKU 1042021277
Manufacturer FAAC International Inc.
Operator Type Swing
Gate Orientation Left-Hinged Gates, Right-Hinged Gates
Color Stainless Steel
Max Gate Length 18 ft.
Max Gate Weight 1,500 lbs.
Max Opening Angle 90 Degree Opening
Operator Kit Type Operator Only
Oil Type Arctic Oil
Mounting Above Ground
Operator Series 400 CBAC EG
