FAAC Complete Range - High-Voltage Swing Gate Openers
Our high-voltage swing gate openers are built for heavy-duty gates in residential, commercial, or industrial environments. Most of these models are available in 115V or 230V models and are a great addition to turning your existing kit into a dual gate system. Having a dependable and reliable swing gate opener is paramount to any gate system for the security and safety of those in it.
400 CBAC EG Long Hydraulic Swing Gate Opener
The 400 EG hydraulic swing gate opener is perfect for any commercial apartment, condo, or residential use. It operates on 115V and features quiet operation due to its hydraulic technology. This gate opener has a self-lubricating feature that ensures a long life. There is a manual release in the event of a power failure. The manual release is key-protected. The maximum leaf length is 18 feet, and the maximum leaf weight is 1500 pounds which will be plenty for most applications, whether it is industrial, commercial, or residential.
Key Features:
- Use Frequency (cycles per hour): 50
- Rod Extension Speed: 0.6 in/sec (1.5 cm/sec)
- Maximum Leaf Weight: 1500 lb (680 Kg)
- Maximum Leaf Length: 18 ft (5.5 m)
- IP55
- Key protected manual release
- Hydraulic lock of the gate in open and closed positions
- Input Voltage: 115 VAC (+10% -6%)
Learn More
View Brochure
402 CBC Hydraulic Swing Gate Opener
The 402 is the perfect entry-level hydraulic swing gate opener for residential applications. Its quiet operation is dependable in temperatures ranging from 4°F to 131°F. You can lock the gate in closed positions thanks to the hydraulic lock. Its compact design is ideal for tight-space installations. The 402 swing gate opener is self-lubricating, ensuring a long life.
Key Features:
- Quiet Operation
- Leaf Max. Width: 10 ft (3 m)
- Lead Max. Weight: 900 lb (410 Kg)
- Usage Frequency (cycles per hour): 55
- IP55
- Thermal Protection on Motor Winding: 248 °F (120 °C)
- Hydraulic Lock Of The Gate In Closed Positions
- Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
Learn More
View Brochure
412 DX Swing Gate Opener
The 412 DX swing gate opener is great for small families and light residential use. It can operate gates up to 14 feet and weigh 500 pounds. A mechanical lock can be actuated in the open or closed position along with a manual release in the event of a power failure. This gate opener was designed for single-family applications. The electronic control board has an anti-crushing safety feature built in.
Key Features:
- Leaf Maximum Length: 14 feet (4.2 m)
- Leaf Maximum Weight: 500 lbs (226.8 kg)
- Use Frequency (Cycles per Hour): 18
- Rod Extension Speed: 0.6 in/s (1.5 cm/s)
- Use Frequency: 100%
- IP44
- Simple Installation And Maintenance
- Designed For Light Residential, Single Family Use
Learn More
View Brochure
415 Swing Gate Opener
The 415 swing gate opener was designed for single-family use in mind. It has a die-cast aluminum body that is double-coated for a longer life. In case of a power failure, there is a manual release with key protection. This compact opener is easy to install and maintain. Built-in sealed limit switches can be used for slowdowns or stops. The opener can be installed near the ground thanks to the horizontal exit for the cables.
Key Features:
- Use Frequency (Cycles per Hour): 25
- Leaf Maximum Length: 15 feet (4.6 m)
- Leaf Maximum Weight: 700 lbs (317.5 kg)
- Rod Stroke: 15. 7 in (400 mm)
- Rod Extension Speed: 0.63 in/ sec (1.6 cm/sec)
- IP54
- Thrust: 674 lbf (300 daN)
- Manual Release Device With Simplified Key-Protected Activation
Learn More
View Brochure
422 CBAC Hydraulic Swing Gate Opener
The 422 hydraulic swing gate opener is perfect for residential homes and condominium complexes. It can cycle up to 55 times an hour which is ideal for light traffic environments. Typically, hydraulic swing gate openers are inherently safer than other types of openers due to them having fewer pinch points. There is a key-protected manual release included. If you are looking for a quiet, long-lasting gate made for light commercial or residential use, the 422 is the way to go.
Key Features:
- Key-Protected Manual Release
- Leaf Max. Weight: 900 lb (410 Kg)
- Leaf Max. Width: 10 ft (3 m)
- Usage Frequency (cycles per hour): 55
- Quiet Operation
- IP55
- Rod Extension Speed: 0.5 in/sec (1.3 cm/sec)
- Pump Flow Rate: 1 l/min
Learn More
View Brochure
750 CBAC In-Ground Hydraulic Pump Motor Assembly with Enclosure
The 750 hydraulic swing gate opener features self-lubrication and quiet operation. Since this is installed underground, there are no worries about ruining a gate aesthetic. It is also much safer than many others because of its low profile and almost invisible installation. This gate opener can be used for residential up to commercial facilities. The hydraulics will ensure a long-lasting and quiet operation for years to come.
Key Features:
- Use Frequency (cycles per hour): 45
- Max. Leaf Width: 13 ft (4 m)
- Max. Leaf Weight: 1700 lb (800 Kg)
- The Ideal Solution For Artistic Gates
- Dimensions: 9.6 x 13.9 x 5.5 in (245 x 353 x 141mm)
- IP55
- Input Voltage: 115 VAC (+10% -6%)
- UL325 Listed
